2017 HONDA 15 HP BF15D3SHS Outboard Motor

• Reliable, efficient 4-stroke design
• Large Displacement – better performance
• Easy One Hand Starting
• Lightweight Design
• Available with Power Thrust Design (BFP models only) – better performance for heavy loads
• Reverse Exhaust Relief – increased maneuverability (BFP models only)
• Ultra Low 3 Star CARB Emissions
• True 5 Warranty
• PGM Ignition – optimal operation
• High Output Charging – more power!
• Engine Alert System – Keeps you informed
• 4-Front Corrosion Protection System – Fights the elements
• Longer Tiller Handle – better control
• Auto Start Enrichment – easy starts
• Pendulum Mount System – Smooth operation
• Convenient, Up Front Tiller Controls
• EZ Steer Friction Control
• Shallow Water Drive
• Positive Lubrication – better durability
• 3 Stage Carburetion – better fuel economy
• Integrated Carrying Handle – easier transport

Model	BF15D3SHS
Model Year	2017
SKU	BF15D3SHS-17
Weight	124.0000
Manufacturer	Honda
Country of Manufacture	Japan
Horsepower	15hp
Shaft Length	15″ (Short)
Steering	Tiller
Starting	Electric
Trim & Tilt	Manual
Fuel Delivery	Carburetor
Fuel Tank	External
Cylinder(s)	2
Displacement	350 cc (21.4 cubic inches)
Bore and Stroke	59 mm x 64 mm (2.3 x 2.5 inches)
Full Throttle RPM Range	4,500-5,500 RPM
Ignition System	PGM-IG
Induction Scavenging	SOHC
Valves per Cylinder	2
Fuel Type	Unleaded Gasoline (86 octane)
Fuel Tank / Fuel Line	3.2 Gal. Fuel Tank + Quick Connect Fuel Line
Oil Type	FC-W 10W-30
Oil Capacity	Please inquire.
Lubrication	Wet Sump
Alternator	12-Amp (148 watt)
Cooling System	Water Cooled
Saltwater Rated	YES
Gear Ratio	2.08:1
Gear Shift	Forward, Neutral, Reverse
Propeller	9¼ x 10 in 4-blade Aluminum
Internal Battery	NO
