For those who want power, performance and portability The sun just broke the horizon, but your day began hours ago—the second you started your trusty Yamaha Portable. Maybe you’re skimming the marsh in a Jon boat during duck season, pushing a sailboat ‘til the wind kicks up, or hopping to the cuddy on a tender. Wherever the day takes you, these nimble

• SOHC

• Large Displacement Engine

• Streamlined Intake Manifold

• Large Volume Air Silencer

• Labyrinth Exhaust

• Water-Cooled Fuel Pump

• Acceleration Pump

• Long Span Mounting System

• Four-Stroke Engine Design

The year 2017 Manufacturer Yamaha Marine Model Name F15 Trim Name LEHA Generic Type (Primary) Four Stroke Engine Engine Type 2 Cylinder Engine Power 15 hp @ 5500 rpm Alternator (Output): 10A ** Displacement 22.1 ci (362 cc) Gear Ratio (Primary) (27:13) 2.08:1 Lubrication Wet sump Fuel Type Induction: SOHC Ignition System: CDI Micro Computer Oil Type (Recommended): Yamalube® 4M (See owner’s manual) Fuel Type (Recommended): Regular Unleaded (Minimum Pump Octane 87) Fuel Type (Recommended Filtration): Yamaha Mini 10-Micron Fuel/Water Separating Filter (external) Spark Plug Spark Plug DPR6EB-900-000 Range Note Full Throttle RPM Range: 5000-6000 Dimensions Length Shaft: L=20″ Bore 2.48 in. (63 mm) Stroke 2.29 in. (58.1 mm) Weights Dry Weight F15LEHA 55kg (122 lbs) Capacities Oil capacity 1.8L/1.6L w/without filter Features Compression Ratio 9.3:1 Features Degree of Tilt: 67°-71° | Degree of Trim: Weight Spec: 2 Note Ethanol Blend Limit: 10% Maximum Note Gear Shift: Forward, Neutral, Reverse Features C.A.R.B. Rating: 3 Star Steering Angle (Maximum): 45° from center, in either direction Cooling Water/Thermostatic Control Note Mounting Centers: 28.6″ Intake Design Carburetor Starter Manual or Electric Warranty Warranty 3 Year Limited Pleasure Boat – 1 Year Limited Commercial
